This webinar introduces a new workflow that links resin flow analysis and structural analysis based on a multiscale approach โ Sign Me Up
Overview
Multiscale technology enables the observation of anisotropic material behavior and obtaining material constants based on a microstructure FE model that consist of fibers and resin, which include voids in some cases. By compiling material constants for various microstructures as a database, you can accurately map the distribution of fiber orientation to material constants. The multi-scale theory facilitates structural analysis of resin-molded products, addressing not only elastoplastic problems but also diverse nonlinear behaviors such as viscoelasticity, creep, and so on.
Presenters
Koji Yamamoto, Developer of Multiscale.Simโข and Technology Specialist, CYBERNET Japan
The webinar is hosted by CoreTech System Co., Ltd. (Moldex3Dยฎ).
What you will learn
- Basics of multiscale analysis for fiber reinforced plastics.
- Analysis method to improve the quality of injection molded products.
- Analysis method to improve the quality of resin transfer molded products.
Download this brochure for more information: Nonlinear Structural Analysis with Consideration for Fiber Orientation of Injection Molded Parts
