Mechanism To Increase Energy Efficiency.

View the figure attached. It is about using Cam for increase
energy efficiency. Cam are generally used to open and close valve of IC
Engine. I am going to show you another use. Left side initial position.
Right side final position. Redius of cam continuously decrease.Sliding
weight (MG) applied on Cam. With the help of rope weight(MG*Cos(b)) is
fixed with cam. We consider b as 45. So cos 45=.70. This fixed weight
should be 0.70 MG. Which balance the sliding weight applied on cam in
tengential direction. As sliding weight come down the fixed weight go
up. But the twist is the redius of cam decrease nominal continuously.
So sliding weight come down little bit and fixed weight go up much
more. We consider sliding weight come dowm H2 height and fixed weight
go up H1 height. We consider H1=5H2
Now we calculate energy loss by sliding weight=MG*Height
=MG*H2
Energy got by lifting fixed weight =MG*Cos(b)*Height
=MG*Cos45*H1
=.70MG*5H2 (Because H1=5H2)
=3.5MGH2
=3.5* Energy loss by sliding weight
So we get 3.5 times more energy than we loss. The ratio depend on the rate we decrease redius of cam and angle (b).
